Change Log Date Chapter Description 11.03.2023 Al Chapters
Consolidated Version (EN) created 1 I Confidential © 2023
VinFast VF5 - Technical Training Information VF5 Technical Product Training Information Part 1 Part 1, Chapter 1 - 5.1.3 Draft Version EN 01.01 I Confidential © 2023 Purpose of the Document •
To provide information which trainers can use when developing or providing technical
training to VinFast service employees. •
Covers a variety of significant vehicle functions and systems. •
Intended users include VinFast Training Centers and 3rd Party training providers. •
It does not provide specific instructions on how to diagnose, repair or replace components. •
Additional Service information is available in the Service Technical Portal (STP), including the following; o
Service Instructions (Remove & Replacement) o
Diagnostic Trouble Code (DTC) guided repair instructions o Emergency Response Guide (ERG) o Service/Maintenance Schedule o
Electronic Parts Catalogue (EPC) 3 I Confidential © 2023
VinFast VF5 - Technical Training Information Disclaimer •
To the best of our knowledge, the il ustrations, technical information, data and
descriptions in this issue were correct at the time of going to publish this document. •
The right to change prices, specifications, equipment and maintenance instructions at
any time without notice is reserved as part of our policy of continuous development
and improvement for the benefit of our customers. •
No part of this publication may be reproduced, stored in a data processing system or
transmitted in any form, electronic, mechanical, photocopy, recording, translation or by
any other means without prior permission. •
No liability can be accepted for any inaccuracies in this publication, although every
possible care has been taken to make it as complete and accurate as possible. • Copyright ©2023 4 I Confidential © 2023
VinFast VF5 - Technical Training Information Note •
Please remember that our training literature has been prepared for TRAINING PURPOSES only. •
Repairs and adjustments MUST always be carried out according to the instructions
and specifications in the workshop literature. •
Please make ful use of the training offered by Technical Training to gain extensive
knowledge of both theory and practice. •
No liability can be accepted for any inaccuracies in this publication, although every
possible care has been taken to make it as complete and accurate as possible. • Copyright ©2023 5 I Confidential © 2023
VinFast VF5 - Technical Training Information Foreword •
VinFast aims to protect the global environment, therefore our approach is to lead the
industry with regenerative environmental technology. •
As Vietnam`s first automotive manufacturer, with the smart electric vehicle portfolio
VinFast offered ful y electric powered vehicles produced in mass production for the Vietnam market. 11 I Confidential © 2023
VinFast VF5 - Technical Training Information Contents – (1/4) 1. Technical Overview​ 4. High Voltage (HV) System
1.1 Vehicle Details; size, weight, range, technical specifications 4.1 HV Overview
1.2. Location of major vehicle components 4.2 HV Technical Information 1.3 Vehicle Features
4.3 HV and Battery Safety for Technicians 1.4 Common Serviceable Items 1. HV Training 1.5 PDI 2. Hazards 2. Basic Operation of Vehicle
3. Personal Protective Equipment (PPE)
2.1 Smart Key and Locking/Unlocking
4. HV Isolation - MSD, Cut Loops
2.2 Turning Vehicle On/Off & Power States 5. HV Marking / Identification
2.3 Selecting gear, park brake, acceleration and braking 4.4 HV Battery Servicing
2.4 Owner’s Manual and Customer Mobile App (C-App) 4.5 HV Battery Care 3. Charging ​
4.6 HV Battery Storage and Transportation
4.7 HV Battery Inspection after an Accident 3.1 Charge Port
4.8 HV Battery Fire Risk and Response
3.2 Fast and Slow Charge Adapters 3.3 Indicator Lights 3.4 Vehicle Display 3.5 Charge Times 3.6 Stopping 12 I Confidential © 2023
VinFast VF5 - Technical Training Information Contents – (2/4) 5. Sub Systems​ 5. Sub Systems​ 5.1 Interior 5.3 Exterior and Closures
1. Instrument Panel​ Cluster (IPC) 1. Exterior Lighting
2. Infotainment System – MHU & MDU 2. Washer & Wiper System
3. Heating Ventilation Air-Conditioning (HVAC) 3. Exterior Mirrors​ 4. Seating
4. Exterior Trim & Underbody Aero Components 5. Airbags, ACM 5.4 Chassis
6. Seatbelts, Pre-tensioners, Load Limiters 1. Suspension
7. Interior/Ambient Lighting, Interior Mirror 2. Brakes 5.2 Electrical
3. Safety, Stability and Traction Control Systems 1. Fuse boxes 4. Steering
2. 12 Volt Battery & Sensor
5. Wheels, Tires & Alignment
3. ECUs (Electronic Control Unit)
6. Tire Pressure Monitoring System (TPMS) 4. Wiring 7. Drive-shafts
5. Multiplex Communication (CAN, LIN) 6. Audio System 7. Other Electrical Components 8. Electrical Testing 13 I Confidential © 2023
VinFast VF5 - Technical Training Information Contents – (3/4) 5. Sub Systems​ 6. Warnings 5.5 Powertrain 7. Special Servicing Tools​
1. EDS (E-Motor, Controller & Transmission)
8. Vehicle Lifting Points​ / Jacking 2. DCDC_OBC_PDU (3 in 1) 3. Regenerative Braking
9. Emergency Equipment​, Call & Response Guide 4. Cooling 10. Care and Cleaning​
5.6 ADAS – Advanced Driver Assistance Systems 11. Towing Operations​
1. Parking Distance Control (PDC)
12. Diagnostics & Programming 2. Rear View Camera 3. Blind Spot Detection 12.1 Introduction 4. Rear Cross Traffic Alert 12.2 Strategy Based Diagnosis 5. Door Opening Warning
12.3 Control Modules (ECU’s) supporting diagnostics 6. Recalibration 12.4 Diagnostic Tool Chain 12.5 DTC Repair Instructions 12.6 Programming (flashing) 12.7 Remote Diagnostics 12.8 Remote Software Updates 14 I Confidential © 2023
VinFast VF5 - Technical Training Information Contents – (4/4)
13. Connected Services & C-App 13.1 Service Booking Tool
13.2 Road Side Assistance (RSA) 13.3 Emergency Call 13.4 Find my Car 13.5 Charge Station Finder 13.6 Dealer Finder 13.7 Thief /Intrusion Alert 13.8 Voice Control 14. Crash Repair Overview 15. Maintenance Schedule 15.1 Service Reminder Reset 16. Service Technical Portal 17. Labour Codes 18. Service Instructions 15 I Confidential © 2023
VinFast VF 8 - Technical Training Information Technical Overview 16 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Model Variants VF5 Variants / Model Lines VN
• Market specific versions for left hand drive regions • VN – Vietnam VF5 17 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Body in White VF5 SUV Platform: • Steel body construction
• Function-specific material strength
design to achieve high body strength.
• Safety focused crash performance (pink parts/blue parts)
• Ultra high strength plate and aluminum HC420/780DP extrusions for Side Pole HC340/590DP
(violet parts/green parts) HC820/1180DP
• Mechanical fixed body components (black AL6082 painted parts) 18 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Body Components HC420/780DP HC340/590DP HC820/1180DP AL6082
“High strength steel plate“ “Black Paint Components“
“Ultra high strength plate and aluminum extrusions“ 19 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Body Variants • One Body Variant • Steel Panel Roof Steel Panel Roof 20 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Powertrain
BEV – Battery Electric Vehicle FWD – Front Wheel Drive
Max. power per EDS 100 kW / 8000rpm
Max torque per EDS 135 Nm / 6500rpm High Voltage Battery 38.6 kWh capacity 400 V nominal Voltage Charging Standard: CCS2 – Vietnam Range: NEDC Test: 300 km 21 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Chassis Chassis Description / Variants Front: MacPherson suspension Rear: Torsion beam axle
Front Independent Wheel suspension Steel coil springs Front stabilizer
Liquid pressure shock absorbers Electric Power Steering EPS Hydraulic Power Braking System 17” Aluminum Alloy wheels 22 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Safety Passive Safety Features:
Occupant compartment design as safe cel with crash load paths
Energy absorbing design of crash elements Door impact beams
Latest safety restraint technology with belt
tensioners and belt force limiters for front seats.
Up to 6 airbags for front and side crash protection 23 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – ADAS Wait for picture to update
Advanced Driver Assist Systems: Economic & Sport functions BSD dead spot monitoring function 24 I Confidential © 2023
VinFast VF5 - Technical Training Information
1.1 Vehicle Details – Smart Services Wait for picture to update Connected Car: Latest Infotainment Technology with central 8” Multimedia Display Unit. Advanced Mobile Device appearance with integrated Apple Car Play and Android Auto functionality. 25 I Confidential © 2023
